USB-C DOCKING STATION 8-IN-1 MULTIPORT
Code
UCHT580
Description
USB-C 8-in-1 Multiport Docking Station with HDMI, Gigabit LAN, 3x USB-A data ports, 1x USB-C PD 100W power port, 1x micro SD slot, and 1x SD slot
Dimensions
110x43x16mm
Manufacturer
Simplecom
Video
1x HDMI 2.0
Power
1x USB-C PD 3.0 100W
Data
3x USB-A 3.2 Gen 1; 1x 1000M RJ45; 1x Micro SD slot; 1x SD card slot
Plug 2
Multimedia
Plug 1
USB-C
Plug
USB-C; Multimedia
Qty
Cost Inc GST
Cost Ex GST
ORDER CODE:
UCHT580
STOCK STATUS
INSTOCK
QTY
EXPANDS YOUR LAPTOP CONNECTION WITH A SINGLE USB-C CONNECTION
8-in-1 USB-C multiport docking station for connectivity expansion to your laptop. Single USB-C to 3x USB-A ports, HDMI, Gigabit Ethernet, SD, micro SD, and USB-C PD. SuperSpeed USB ports support data transfer rates up to 5Gbps. HDMI 2.0 port supports up to 4K@60Hz resolution in mirror or extended mode. Gigabit Ethernet supports connection speeds of up to 1000Mbps. USB-C PD port for charging the laptop with up to 100W of power. 2-Slot Card Reader for SD and MicroSD Memory Cards. Durable & stylish aluminium alloy housing. Lightweight and portable, easy to carry along when travelling. Built-in flexible USB-C cable. Plug & play, no driver software required.
Host Interface: USB-C.
USB Hub: 3x USB-A Female (SuperSpeed 5Gbps).
HDMI Resolutions: Support up to 3840 x 2160p at 60Hz (4K@60Hz).
Network Port: RJ45 Gigabit Ethernet (10/100/1000 Mbps).
Card Reader: SD and MicroSD (Hi-Speed 480Mbps).
PD Charging: 1x USB-C Female (for charging only), up to 100W.
Operation Temperature: 0 - 45°C.
Housing Material: Aluminium.
Dimensions: 110x43x16mm.
Cable Length: 15 cm.
Weight: 67g.
Note: Before purchasing, please confirm the USB-C port on your device supports DisplayPort Alternate Mode (DP Alt Mode). Some USB-C ports only work for charging or data transfer, no video output function.
4K@60Hz is supported by laptop GPU with DP1.4 (e.g. Intel 11th Gen Core Mobile Processors or later).
The USB-C PD port is for PD Charging only, not for data transfer.
Only one SD or MicroSD card can be accessed at a time.
For more stable connection when using multiple devices, connect a PD power adaptor to the USB-C PD port for extra power.
EXPANDS YOUR LAPTOP CONNECTION WITH A SINGLE USB-C CONNECTION
8-in-1 USB-C multiport docking station for connectivity expansion to your laptop. Single USB-C to 3x USB-A ports, HDMI, Gigabit Ethernet, SD, micro SD, and USB-C PD. SuperSpeed USB ports support data transfer rates up to 5Gbps. HDMI 2.0 port supports up to 4K@60Hz resolution in mirror or extended mode. Gigabit Ethernet supports connection speeds of up to 1000Mbps. USB-C PD port for charging the laptop with up to 100W of power. 2-Slot Card Reader for SD and MicroSD Memory Cards. Durable & stylish aluminium alloy housing. Lightweight and portable, easy to carry along when travelling. Built-in flexible USB-C cable. Plug & play, no driver software required.
Host Interface: USB-C.
USB Hub: 3x USB-A Female (SuperSpeed 5Gbps).
HDMI Resolutions: Support up to 3840 x 2160p at 60Hz (4K@60Hz).
Network Port: RJ45 Gigabit Ethernet (10/100/1000 Mbps).
Card Reader: SD and MicroSD (Hi-Speed 480Mbps).
PD Charging: 1x USB-C Female (for charging only), up to 100W.
Operation Temperature: 0 - 45°C.
Housing Material: Aluminium.
Dimensions: 110x43x16mm.
Cable Length: 15 cm.
Weight: 67g.
Note: Before purchasing, please confirm the USB-C port on your device supports DisplayPort Alternate Mode (DP Alt Mode). Some USB-C ports only work for charging or data transfer, no video output function.
4K@60Hz is supported by laptop GPU with DP1.4 (e.g. Intel 11th Gen Core Mobile Processors or later).
The USB-C PD port is for PD Charging only, not for data transfer.
Only one SD or MicroSD card can be accessed at a time.
For more stable connection when using multiple devices, connect a PD power adaptor to the USB-C PD port for extra power.
