2 OHMS PER COIL

15" MAX-X HIGH EXCURSION DVC SUBWOOFER

Your current selection:

  Product Description

15" MAX-X HIGH EXCURSION DVC SUBWOOFER

2 OHMS PER COIL

Description:

The 15" dual voice coil high excursion subwoofer from Dayton Audio is built for incredible low frequency extension and high SPL. This affordable driver combines durability, efficiency, and maximum displacement into a great looking speaker that will deliver the deepest bass with power and authority. Optimised for use in compact enclosures this driver is ideal for home subwoofer designs and high impact car audio systems.

  • ±24 mm Klippel verified excursion and maximized surface area for excellent displacement capability.
  • Seamless dish cone is extremely rigid and durable with a sleek and modern look.
  • Custom tooled surround allows long throw while maximizing cone surface area.
  • Extensive venting cools the voice coil enabling high power handling with low power compression.
  • Dual spiders maintain linear excursion for lower distortion even when pushed to the limit.
  • The dual 2 ohm voice coils give you the ability to get the most out of any amplifier.





  • buy










    Order Code DESCRIPTION MANUFACTURER CMS COIL DEPTH DIAM. FS HOLE IMPEDANCE IMPEDANCE (OHM) INCH LE MMS POWER POWER (RMS) PRICE TYPE QES QMS QTS RE SD SENS. SERIES SIZE TYPE VAS ZN More Info
    dummny img
    MX15-22 15" Max-X High Excursion DVC Subwoofer 2 Ohms Per Coil Dayton Audio 0.16mm/N 63.5mmØ 232mm 392mmØ 21.7Hz 356mmØ 2+2Ω (Re 3.99Ω) 2+2 ohm 15 5.51mH 348g 800W 200+ Watt each 0.46 4.27 0.4 3.99Ω 819.8cm² 90.2dB Max-X Series 15" DVC Subwoofer 146L 2+2Ω img
    Details

    DescriptionFileSize
    DatasheetMX15-22.pdf538 KB
    MX15-22 - Product Downloads

    Description File Size
    Datasheet MX15-22.pdf 538 KB
