			Product Description
			CELLULAR WIDE BAND LOG PERIODIC ANTENNA GSM/NEXT-G/3G/4G/LTE NETWORKS

			16dBi - 14dBi HIGH GAIN DIRECTIONAL 824MHz - 2500MHz WIDE BAND SUITS ALL AUSTRALIAN CELLULAR & WIRELESS INTERNET NETWORKS Description: This alloy antenna has pre-attached cable and FME-Female plug for easy installation and minimal loss. Choose between cable type, length and plug. Aluminium construction made in Australia. Mast U-Bracket included for pole mount. Vertical polarised. Logarithmic Periodic with 52 elements. Element 52 Gain 16-14dBi Freq. 824-1000MHz 1700-2170MHz Ratio >25dB Polorised Vertical Horz. 48° Vert. 60° VSWR <2.1:1 Power 10W Length 1100mm Imp. 50Ω

Tip! Narrow products in this family using filter options on the left!

View Product Category
See All products in the same Product category

Products
Ask a Question
Bulk Buy / Project Pricing
Downloads

	Order Code	CABLE	DESCRIPTION	LENGTH	PLUG	More Info
	ANT455	RG58CU	Wide Band Cellular Directional LOG Antenna With 8m Cable	8M	FME-Female	Details
	ANT456	LL195	Wide Band Cellular Directional LOG Antenna With 11m Cable	11M	FME-Female	Details
	ANT457	LL195	Wide Band Cellular Directional LOG Antenna With 40cm Cable	0.4M	N-Female	Details

No downloads currently available for this product.
